Name: Bently Nevada 143493-01 Proximity Probe
Brand: YonaNex Limited
SKU: 1600658487837
Price: 1.00 USD
Availability: InStock
Rating: 5 (1 reviews)

Description

Bently Nevada 143493-01 Proximity Probe

Place of Origin

United States

Application

Automation

Material

Stainless Steel

Brand Name

bently nevada

Model Number

143493-01

Product name

143493-01

Frequency Response

10 Hz to 1 kHz (600 cpm to 60 kcpm)±10%

Excitation Voltage

12 to 30 Vdc (current limited to 40 mA)

Operating Temperature Range

-40℃ to +85 ℃ (-40 ℉ to +185℉ )

Temperature Range

-58 to 250°F (-50 to 121°C)

Case Material

316L stainless steel

Output Format

4 to 20 mA current loop Velocity vibration

Linearity

±1%

Mounting Torque

4 to 7 N-m (35.4 to 62.0 in-l

Product Description

Overview

The 3300 XL probe and extension cable also reflect improvements over previous designs. A patented TipLoc™ molding method provides a more robust bond between the probe tip and the probe body. The probe’s cable is more securely attached as well, incorporating a patented CableLoc™ design that provides 330 N (75 lbf) pull strength where the probe cable attaches to the probe tip.

3300 XL 8 mm Probes and Extension Cables can also be ordered with an optional FluidLoc® cable option. This option prevents oil and other liquids from leaking out of the machine through the cable’s interior.

Product Features

Continuous Monitoring in Hazardous Locations
Measures shaft vibration and displacement on machinery with fluid film bearings

1.8 mm probe tip diameter with 3/8-24 or M10x1 threaded body

2.Probe tip and body sealed to prevent leaking through cable

3.Upgraded to include SecureLock Connector

Technical Parameters

Temperature Range	-49 to 350°F (-45 to 177°C)
Sensitivity	-200 mV/mil (-7.87 V/mm) (1 mil = 0.001”)
Material	FEP Cable Jacket with 316L Stainless Steel Probe Body
Case Thread	3/8-24 or M10x1
Wrench Flats	5/16 in or 8 mm (Standard Mount), 7/16 in or 10 mm (Reverse Mount)
Rating	IP68
Connector	SecureLock
