Electrical
|
||
|
Sensitivity
|
10.2 mV/m/s2 (100 mV/g) ±5%.
|
|
|
Frequency Response
|
10 Hz to 15 kHz (600 cpm to 900,000 cpm) ±3dB; 30 Hz to 10 kHz (1800 cpm to 600,000 cpm) ±10%
|
|
|
Temperature Sensitivity
|
-11% to +3% typical over the operating temperature range.
|
|
|
Acceleration range
|
490 m/s2 (50 g) peak overall acceleration within the 10 Hz to 15 kHz frequency span. Vibration at frequencies above 15 kHz,
especially at the transducers resonance will significantly decrease this range. |
|
|
Amplitude Linearity
|
±1% to 490 m/ s2 (50 g) peak
|
|
|
Broadband Noise Floor (10 Hz to 15 kHz)
|
0.039 m/s2 (0.004 g) rms.
|
|
|
Transverse Sensitivity
|
Less than 5% of axial.
|
|
|
Output Bias Voltage
|
-8.5 ± 0.5 Vdc
|
|
|
Input Voltage
|
-24 ± 0.5 Vdc.
|
|
|
Bias Current
|
2 mA nominal
|
|
|
Physical
|
||
|
Weight
|
99 g (3.5 oz), typical
|
|
|
Diameter
|
23 mm (0.93 in).
|
|
|
Height
|
59 mm (2.3 in), including mounting stud.
|
|
|
Case Material
|
316L stainless steel
|
|
|
Connector
|
3-pin MIL-C-5015 Receptacle 316L stainless steel
|
|
|
Mounting Torque
|
4.1 N·m (3.0 ft·lb).
|
|
