Universal Voltage AC
|
||
|
Description
|
This option uses the universal AC
Power Supply and universal AC Power Input Module (PIM). |
|
|
Input Voltage
|
110 to 220 Vac nominal
85 to 264 Vac rms 120 to 373 Vac pk The universal AC Power Supply and Power Input Module are not compatible with the legacy High Voltage AC or Low Voltage AC units. |
|
|
Input Frequency
|
47 to 63 Hz
|
|
|
High Voltage DC
|
||
|
Description
|
This option uses the High Voltage DC Power Supply and the High Voltage DC Power Input Module(PIM).
|
|
|
Input voltage
|
88 to 140 Vdc
|
|
|
Low Voltage DC
|
||
|
Description
|
This option uses the Low Voltage DC Power Supply and the Low
Voltage DC Power Supply Input Module (PIM). |
|
|
Input voltage
|
20 to 30 Vdc
|
|
|
Current Information
|
||
|
Out of Range Protection
|
For all power supply options, an under-voltage does not harm the
supply or the PIM. An over-voltage causes the fuse to open on the PIM. |
|
|
Full Rack Current Draw
|
||
|
Universal
|
2.8 A rms (maximum)
|
|
|
voltage AC
|
||
|
High voltage DC
|
2.5 A (maximum)
|
|
|
Low voltage DC
|
11.0 A (maximum)
|
|
