K21-6-M-B07C-1-4-D-S-XMB31 2130X000S00 F075383 Melt Pressure Transmitter Sensor Made in Italy

Specification:
K21-6-M-B07C-1-4-D-S-XMB31
  • K21-6-M-B07C-1-4-D-S-XMB31 2130X000S00 F075383 Melt Pressure Transmitter Sensor Made in Italy

Description

Mounting Type
Thread
Model Number
K21-6-M-B07C-1-4-D-S-XMB31
Brand Name
Gefran
Usage
Extrusion line
Accuracy
±0.1%
Description
Melt pressure transmitter
Type
Gauge Pressure Sensor
Series
KE KN K3
Features
NaK filled
Place of Origin
Italy
Output
3.33mV/V, 0~10V 4~20MA
Description
melt pressure transmitter
Port Size
1/2-20UNF
Operating Temperature
550C
Pressure Range
0~1500BAR
Pressure Type
gauge pressure
Products name
Melt pressure transducer, transmitter
Brand
gefran
Max pressure
1500bar
Process temperature
550C
Thread size
1/2-20UNF
Accuracy
±0.5 %
Output
3.33mV/V, 0~10V 4~20MA
Media Measured
Liquid
Supply Voltage
10-30 V
Country of Origin
Italy

Packaging and delivery

Selling Units
Single item
Single package size
44X12X10 cm
Single gross weight
2.000 kg
Product Description

Introudction

The melt pressure transmitters are for use in high temperature applications where the process temperatures may reach 538°C (1000°F) such as high temperature engineered polymers. The K Series utilizes standard melt pressure principles and construction, but uses a near incompressible NAK (Sodium Potassium) for pressure transmission. The K Series strain sensing technology is bonded foil strain gage.
Specification
item
value
Series
K21-6-M-B07C-1-4-D-S-XMB31
Pressure range
0~50bar...1500bar
Thread size
1/2-20UNF
Type
NaK filled
Place of Origin
Italy
Brand Name
Gefran
Maximum operating temperature
550°C
Calibration
Internal 80% shunt calibration
Packing & Delivery
